VG Series
Wey VG knife gate valves are products with a special flange. They were specifically developed for biogas applications in agriculture, since standard DIN gate valves for industrial pipelines are not compatible. The VG is available exclusively in cast iron, and only in the nominal sizes DN 150 and DN 200.
CHARACTERISTICS VG series
Nominal sizes: 150 – 200 mm
Material: Cast iron
Pressure rating: 0 – 4 bar
Flange drilling: Special flange
Face to face dimension: EN 558 series 20
Application areas
Biogas plants
e.g. Manure, Substrates ...
Downloads
General documents
Product brochure knife gate valves
Declaration of conformity DGRL
Declaration of incorporation MRL
Data sheets
